To use the ARP and PING commands, you will need to know the printer's MAC address. You can confirm the MAC
address on the Control Panel.
1
Check the printer's MAC address.
You can confirm the MAC address on the Control Panel as follows:
1.
On the Tab Selection screen of the Control Panel, press or to
select the Settings/Adj. tab ( ).
2.
Press the OK button.
The Set./Adj. Menu is displayed.
3.
Press or to select Interface Setup, and then press the OK button.
4.
Press or to select Ethernet Driver, and then press the OK button.
5.
Press or to select MAC Address, and then press the OK button.
Note
If the Tab Selection screen is not displayed, press the Menu button.
You can investigate the MAC address by printing an interface setting report.
(See "Printing Interface Setting Reports.") →P.513
2
In Windows, open a command prompt, or in Mac OS X, start Terminal.
3
Execute the following command to add entries to the ARP table for managing IP addresses and corresponding
MAC addresses.
arp -s [IP address] [the printer's MAC address you have verified]
Example: arp -s xxx.xxx.xxx.xxx 00-1E-8F-xx-xx-xx
Note
In Mac OS X when using Terminal, enter the arp command in the format arp -s xxx.xxx.xxx.xxx 00:1E:8F:xx:xx:xx.
For details, refer to the help file for the command line.
4
Execute the following command to send the IP address to the printer and configure it.
ping [IP address as specified in the ARP command] -l 479
Example: ping xxx.xxx.xxx.xxx -l 479
Note
In -l, the l is the letter l.
In Mac OS X when using Terminal, enter the ping command in the format ping -s 479 xxx.xxx.xxx.xxx. For details,
refer to the help file for the command line.
Note
The subnet mask and default gateway are set to 0.0.0.0. Use RemoteUI to change the subnet mask and default gateway to
match your network settings.
For details on RemoteUI, see "Using RemoteUI." →P.535
iPF765
Configuring the IP Address Using ARP and PING Commands
User's Guide
Network Setting Initial Settings
539
