Canon imagePROGRAF iPF765 User Manual

Storage destination
The storage area on the printer's hard disk is divided into a temporary storage area and a permanent storage area. The
temporary storage area stores print jobs in the job queue or shared mailbox. The permanent storage area stores jobs
in personal boxes.
• Job queue
The job queue refers to print jobs that are being processed by the printer (saved, received, prepared for process-
ing, printed, deleted, or held). Up to 64 jobs can be stored in the temporary storage area.
When the job queue is full, additional jobs sent from a computer are treated as "standby" jobs, to be processed
when possible.
However, if all queued jobs are simply being held, the oldest job is deleted and the print job sent from the comput-
er is processed.
•
Shared mailbox
Jobs for which you have specified Print in Output Method (in Windows) or Send job to (in Mac OS X) are saved
in the shared mailbox and classified as saved jobs.
There is one shared mailbox, numbered 00. A password cannot be set for the shared mailbox.
Up to 100 print jobs can be saved here, but they will be deleted one after another starting with the oldest job in the
following situations.
• If there are more than 100 jobs queued and saved in the shared mailbox combined
• If no more temporary storage space is available when jobs for which you have selected Print in Output Meth-
od (in Windows) or Send job to (in Mac OS X) are received
• If there is not enough space in the temporary or permanent storage area when jobs for which you have selec-
ted Save in mail box in Output Method (in Windows) or Send job to (in Mac OS X) are received
•
Personal boxes
Jobs are classified as saved jobs and saved in personal boxes in the following situations.
• When a saved job stored in the shared mailbox is moved to a personal box
• When you have selected Save in mail box as the option in Output Method (in Windows) or Send job to (in
Mac OS X)
There are 29 personal boxes, numbered 01 to 29. You can specify a name and password for each personal box.
Up to 100 print jobs can be saved in all personal boxes combined.
iPF765
Using the Printer Hard Disk
User's Guide
Print Job Operations Basic Print Job Operations
563

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
