CHAPTER 1 GENERAL DESCRIPTION
1-5
B. Cross Section
(PC420/430/FC220)
(PC400/FC200)
q Copyboard cover
w Copyboard glass
e Cleaning assembly
r Primary charging roller
t Scanning lamp
y Lens array
u Developing cylinder
i Registration roller
o Pick-up roller
!0 Pick-up tray
!1 Transfer charging roller
!2 Photosensitive drum
!3 Fixing assembly
!4 Delivery roller
!5 Delivery tray
!6 Heat exhaust fan
!7 Delivery assembly cover
open/close button
14 1317 16 15 1112
1031 2 4 5 6 7 8 9
12 11 98
Figure 1-301B
