Canon PC430 - Pick-Up Stationary Jam; Pc400;Fc200; Pc420;430;Fc220; Paper Is Present at the Pick-Up or Delivery Sensor at Time of Power-On or When the Copy Start Key Is Pressed

COPYRIGHT © 1998 CANON INC. CANON PC400/420/430,FC200/220 REV.0 JAN.1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 5 PICK-UP/FEEDING SYSTEM
5-9
D. Pick-Up Stationary Jam
The copy paper does not move past the pick-up sensor within a specific period of
time.
1. PC420/430/FC220
Sequence
Copyboard
1
2
3
4
5
STBY INTR
CBRV STOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Copyboard posi-
tion sensor (Q902)
Jam check
Copy Start key ON
Pick-up sensor
(Q131)
Delivery
sensor (Q801)
1 sec
errornormal
1 sec
Sequence
Copyboard
1
2
3
4
5
STBY INTR
CBRVSTOP
COPY
CBFW CBRV CBFW
CBRV
STOP
LSTR
STBY
Power switch ON
Main motor
(M1)
Copyboard posi-
tion sensor (Q902)
Jam check
Copy paper inserted
Pick-up sensor
(Q131)
Delivery sensor
(Q801)
10 sec
errornormal
Copy paper inserted
10 sec
Figure 5-401D (A4)
2. PC400/FC200
Figure 5-402D (A4)
E. Paper is present at the pick-up or delivery sensor at time of
power-on or when the Copy Start key is pressed.
