CHAPTER 5 TROUBLESHOOTING PAPER FEED PROBLEMS
5-1
5
CHAPTER 5 TROUBLESHOOTING PAPER FEED
PROBLEMS
A. Copy Paper Jams
Jams can be classified according to location within the copier:
q Pick-up assembly
w Separation/feeding assembly
e Fixing/delivery assembly
The discussions that follow are organized with reference to these assemblies.
3 2 1
Figure 5-1A
