CHPTER 4 IMAGE FORMATION SYSTEM
2. Operations
a. HVPDC=1, HVPHO=1 (copying)
DC bias control circuit set to ‘-625 V’.
Transformer T106 generates ‘DC bias’.
HVPAC=1
Oscillation control circuit goes ON.
Transformer T103 generates AC bias
Primary charging
(DC bias + AC bias) goes ON.
b. HVPDC=1, HVPHO=0 (document not exposed)
DC bias control circuit set to ‘-240 V’.
Transformer T106 generates DC bias.
HVPAC=1
Oscillation control circuit goes ON.
Transformer T103 generates AC bias.
Primary charging
(DC bias + AC bias) goes ON.
c. HVPDC=0, HVPHO=0 (standby)
DC bias control circuit goes OFF.
Transformer T106 DC bias goes OFF.
HVPAC=0
Oscillation control circuit goes OFF.
Transformer T103 goes OFF.
Primary charging
(DC bias + AC bias) goes OFF.
