FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
100 - NPN
RF
EXTERNAL COVERS, PANELS, ETC. FC220,PC420,430
1
FB1 - 7403 - 000
1
FILM, SLIDE
2
FB1 - 7462 - 000
1
PLATE, BLANKING, FRONT WHITE
FB1 - 9224 - 000
1
PLATE, BLANKING, FRONT GRAY
3
FB1 - 7463 - 000
1
PLATE, BLANKING, REAR WHITE
FB1 - 9225 - 000
1
PLATE, BLANKING, REAR GRAY
4
FB2 - 9670 - 000
1
TRAY, MANUAL PAPER FEED FC220 WHITE
100V
FB2 - 9673 - 000
1
TRAY, MANUAL PAPER FEED FC220 GRAY
100V
FB2 - 9671 - 000
1
TRAY, MANUAL PAPER FEED FC220,PC420 WHITE
115/120/220/240V
FB2 - 9674 - 000
1
TRAY, MANUAL PAPER FEED FC220,PC420 GRAY
115/120/220/240V
FB2 - 9672 - 000
1
TRAY, MANUAL PAPER FEED PC430 WHITE
120V
5
FB3 - 8941 - 000
1
HOOK
6
FB4 - 0026 - 000
1
LABEL, "DENSITY ADJUSTMENT" FC220 100V WHITE
FB4 - 0371 - 000
1
LABEL, "DENSITY ADJUSTMENT" FC220 100V GRAY
7
FB4 - 0058 - 000
1
LABEL, CONTROL PANEL, 2 FC220 100V WHITE
FB4 - 0368 - 000
1
LABEL, CONTROL PANEL, 2 FC220 100V GRAY
8
FB4 - 0287 - 000
1
DIAL, DENSITY CONTROL WHITE
FB4 - 0288 - 000
1
DIAL, DENSITY CONTROL GRAY
9
FB4 - 0307 - 000
1
GUIDE, MANUAL PAPER FEED, F
10
FB4 - 0308 - 000
1
GUIDE, MANUAL PAPER FEED, R
11
FB4 - 0327 - 000
1
TRAY, PAPER DELIVERY FC220,PC420 WHITE
FB4 - 0328 - 000
1
TRAY, PAPER DELIVERY FC220,PC420 GRAY
FB2 - 9663 - 000
1
TRAY, PAPER DELIVERY PC430 WHITE
12
FB4 - 0330 - 000
1
TRAY, SUB FC220,PC420 WHITE
FB4 - 0331 - 000
1
TRAY, SUB FC220,PC420 GRAY
FB2 - 9677 - 000
1
TRAY, SUB PC430 WHITE
13
FB4 - 0330 - 000
1
TRAY, SUB FC220,PC420 WHITE
FB4 - 0331 - 000
1
TRAY, SUB FC220,PC420 GRAY
14
FB4 - 0352 - 000
1
KEY TOP, MAIN SWITCH
15
FB4 - 0375 - 000
1
LABEL, CONTROL PANEL, 1 FC220 100V WHITE
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
100-2
