Canon PC430 - Page 207

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
100A - NPN
RF
EXTERNAL COVERS, PANELS, ETC. FC200,PC400
1
FB1 - 7403 - 000
1
FILM, SLIDE
2
FB1 - 7462 - 000
1
PLATE, BLANKING, FRONT WHITE
FB1 - 9224 - 000
1
PLATE, BLANKING, FRONT GRAY
3
FB1 - 7463 - 000
1
PLATE, BLANKING, REAR WHITE
FB1 - 9225 - 000
1
PLATE, BLANKING, REAR GRAY
4
FB3 - 8743 - 000
1
GUIDE, MANUAL PAPER FEED, F
5
FB3 - 8744 - 000
1
GUIDE, MANUAL PAPER FEED, R
6
FB3 - 8938 - 000
1
HOOK
7
FB4 - 0263 - 000
1
LABEL, CONTROL PANEL FC200 100V WHITE
FB4 - 0264 - 000
1
LABEL, CONTROL PANEL FC200 100V GRAY
8
FB4 - 0328 - 000
1
TRAY, PAPER DELIVERY UTP,UTQ,ZTH
FB4 - 0327 - 000
1
TRAY, PAPER DELIVERY ZTG
9
FB4 - 0331 - 000
1
TRAY, SUB UTP,UTQ,ZTH
FB4 - 0330 - 000
1
TRAY, SUB ZTG
10
FB4 - 0352 - 000
1
KEY TOP, MAIN SWITCH
11
FG5 - 9486 - 000
1
UPPER COVER UNIT FC200 100V WHITE
FG5 - 9489 - 000
1
UPPER COVER UNIT FC200 100V GRAY
FG5 - 9487 - 000
1
UPPER COVER UNIT FC200 220/240V WHITE
FG5 - 9490 - 000
1
UPPER COVER UNIT FC200 220/240V GRAY
FG5 - 9488 - 000
1
UPPER COVER UNIT PC400 120V WHITE
FG5 - 9491 - 000
1
UPPER COVER UNIT PC400 120V GRAY
12
FS5 - 2355 - 000
1
SPRING, COMPRESSION
501
XB4 - 7401 - 009
1
SCREW,TAPPING,TRUSS HEAD,M4X10
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
100A-2
