FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
160 - FG5 - 9572 - 000
1
COPYBOARD COVER ASSEMBLY FC220 LTH,LTL
FC200 LTM,LTG
FG5 - 9573 - 000
1
COPYBOARD COVER ASSEMBLY FC220 NVD,PTR,RTM,
UTR,UTS,PTS,PTT
FC200 PTQ,RTL,UTP,
UTQ,PTV PC400 PC420
1
FB4 - 0027 - 000
1
RAIL
2
FB4 - 0029 - 000
1
PLATE, RACK SUPPORT
3
FB4 - 0030 - 000
1
SHEET, RACK GUIDE
4
FB4 - 0310 - 000
1
MOUNT, RACK
5
FB4 - 0372 - 000
1
PLATE, VERTICAL SIZE INDEX A4/A5 B5/B6
FB4 - 0373 - 000
1
PLATE, VERTICAL SIZE INDEX A4/A5 B5
LTR/STMT
6
FF5 - 6407 - 000
1
COVER, COPYBOARD SEE NOTE
WHITE
FF5 - 6408 - 000
1
COVER, COPYBOARD SEE NOTE
GRAY
6A
FB1 - 7451 - 000
1
SHEET, COPYBOARD SEE NOTE
7
FN1 - 4327 - 000
1
GLASS, COPYBOARD
8
XA9 - 0762 - 000
3
SCREW,RS,M3X8
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
160-2
