Canon PC430 - Page 226

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
161 - FG5 - 4787 - 000
1
COPYBOARD COVER ASSEMBLY PC430
1
FB1 - 7438 - 000
1
CAM, REGISTRATION
2
FB1 - 7439 - 000
1
SHEET, RACK GUIDE
3
FB1 - 8865 - 020
1
RAIL
4
FB1 - 8874 - 000
1
SUPPORT, RAIL SEE NOTE
PC430
5
FB2 - 9728 - 000
1
RACK
6
FB2 - 9732 - 000
1
PLATE, SIZE INDEX LTR/STMT/LGL
A4/A5
7
FF5 - 6409 - 000
1
COVER, COPYBOARD SEE NOTE
PC430
7A
FB1 - 8870 - 000
1
SHEET, COPYBOARD SEE NOTE
PC430
8
FN1 - 4329 - 000
1
GLASS, COPYBOARD
501
XB4 - 7300 - 609
1
SCREW,TAPPING,TRUSS HEAD,M3X6
502
XB4 - 7300 - 609
1
SCREW,TAPPING,TRUSS HEAD,M3X6 SEE NOTE
PC430
503
XB5 - 2300 - 509
1
SCREW,CT,M3X5
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
161-2
