FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
320 -
FG5 - 9535 - 000
1
REGISTRATION ROLLER ASSEMBLY
1
FB1 - 7316 - 000
2
BUSHING
SEE NOTE
2
FB1 - 7317 - 000
1
GEAR, 20T
3
FB1 - 7319 - 000
1
RING, CONTROL
4
FB1 - 7344 - 000
1
RUBBER, RING
5
FB2 - 9594 - 000
1
ROLLER, REGISTRATION, LOWER
6
FB2 - 9595 - 000
1
SUPPORT, REGIST. ROLLER, FRONT
7
FB2 - 9596 - 000
1
SUPPORT, REGIST. ROLLER. REAR
8
FB2 - 9599 - 000
1
DRUM, CLUTCH
9
FB2 - 9600 - 000
1
ROLLER, REGISTRATION, UPPER
SEE NOTE
10
FB4 - 0053 - 000
1
ARM, PRESSURE RELEASE, FRONT
11
FB4 - 0054 - 000
1
ARM, PRESSURE RELEASE, REAR
12
FB9 - 0001 - 000
2
RING,E
13
FS5 - 2349 - 000
2
SPRING, TENSION
SEE NOTE
14
FS5 - 2351 - 000
1
SPRING, CLUTCH
15
FS6 - 0345 - 000
1
GEAR, 18T
SEE NOTE
16
FS6 - 0347 - 000
1
GEAR, 20T
501
XD1 - 1104 - 132
1
SHIM
502
XD3 - 2160 - 062
1
PIN,DOWEL
503
XD3 - 2160 - 162
1
PIN,DOWEL
