FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
B - NPN
RF
LIST OF CONNECTORS
J202
PCB DC CONTROLLER/DC POWER SUPPLY
FH2 - 6223 - 000
1
CABLE, FLAT FC220,PC420,430
FH2 - 6224 - 000
1
CABLE, FLAT FC200,PC400
J601
PCB CONTROL PANEL
FH2 - 6223 - 000
1
CABLE, FLAT FC220,PC420,430
FH2 - 6224 - 000
1
CABLE, FLAT FC200,PC400
J603
PCB CONTROL PANEL
VS1 - 0842 - 005
1
CONNECTOR, 5P, FEMALE
J621
PCB CONTROL PANEL
VS1 - 0842 - 004
1
CONNECTOR, 4P, FEMALE
J801
PCB DELIVERY SENSOR
VS1 - 0978 - 003
1
CONNECTOR, 3P, MALE
J901
PCB DC CONTROLLER/DC POWER SUPPLY
NPN SOLENOID SL1
J902
PCB DC CONTROLLER/DC POWER SUPPLY
NPN COPYBOARD DRIVE SOLENOID SL2
J903
PCB DC CONTROLLER/DC POWER SUPPLY
NPN COPYBOARD DRIVE MOTOR
J904
PCB DC CONTROLLER/DC POWER SUPPLY
PCB MOTOR DRIVE SENSOR
J905
PCB DC CONTROLLER/DC POWER SUPPLY
PCB COPYBOARD HOME POSITION SENSOR
J906
PCB DC CONTROLLER/DC POWER SUPPLY
PCB LAMP
J907
RH2 - 5336 - 000
1
CONNECTOR, DC
VS3 - 0198 - 003
1
CONNECTOR, 3P, MALE
J908
PCB DC CONTROLLER/DC POWER SUPPLY
NPN FIXING UPPER UNIT
J909
PCB DC CONTROLLER/DC POWER SUPPLY
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
B-2
