CDE360 Vector Control AC Drive Chapter 2 Product Information
Item
Specifications
Special
Functions
The delay time of
terminals
The user can set the delay time for digital input terminals, digital
output terminals and relays.The time range is 0.0s to 3000.0s.
JOG Control
Control mode: keypad, terminals and serial communication.
Frequency: 0.00Hz to Maximum frequency;
Ramp time: 0.1 to 6000.0s
Multiple speed and
simple PLC
Based on built-in PLC or digital input terminals, realize the
running of sixteen segments speed.
Two PID inside the
parameters
As common PID, the closed-loop system of process control can be
realized easily.
Fixed length and count
The AC drive can count the pulse signal of 0 to 100K Hz and realize
the control of count reaching by using digital output terminals.The
drive can also convert the count into length for display and control.
Spinning and swing
frequency
The fixed swing magnitude, fixed mutations and fixed periodic
output can be achieved at arbitrary frequency.
Timing control
Time range: 0 to 65000 hours.
The timing control can stop the AC drive.
Power loss ride
through
When the power loss ride through happens, by decreasing the
running frequency, the feedback energy of the load can
compensate the voltage drop of the DC bus. As a result, the AC
drive can keep running for a short time.
Peripheral
terminals
Reference power
10V/30mA.
Usually, it is used for the power supply of analog input signals.
Control power
24V/200mA.Usually, it is used for the power supply of digital input
and output terminals.
Analog input
Two analog input terminals, which have two types of voltage input
and current input.
Every input terminal can support three types input signals: 0 to 10V,
0 to 20mA and -10V to 10V.
These two analog input terminals are programmable.
Analog output
Two analog output terminals, which have two types of voltage
output and current output.
Every output terminal can support two types output signals: 0 to
10V and 0 to 20mA.
These two analog output terminals are programmable.
Digital input
Five multi function digital input terminals are compatible with active
PNP or NPN input mode. Among these six input terminals, the X6
terminal can be chosen as high-speed pulse input terminal and the
range of the high-speed pulse is 0 to 100KHz. At the same time, the
X6 terminal is programmable.
Digital output
There are two open collect output terminals. Among them, Y2
terminal can be chosen as high-speed pulse output. These two
output terminals are programmable.There are two relay output
terminals.
