CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-58-
C2 Analog Input
Function
Code
Name
Range
Default
Step
Description
C2.00
AI1 filter time
0.00~10.00
0.10
0.01Sec
C2.01
AI2 filter time
0.00~10.00
0.10
0.01Sec
C2.02
AI3 filter time
0.00~10.00
0.10
0.01Sec
C2.03
AI curve selection
111~333
321
1
1: AI curve 1(C2.04~07)
2: AI curve 2(C2.08~11)
3: AI curve 3(C2.12~15)
Unit's digit: AI1
Ten's digit: AI2
Hundred's digit: AI3
C2.04
AI curve 1 minimum input
-10.00~C2.06
0.00
0.01V
C2.05
Corresponding setting of
AI curve 1 minimum input
-100.0~100.0
0.0
0.1%
C2.06
AI curve 1 maximum input
C2.04~10.00
10.00
0.01V
C2.07
Corresponding setting of
AI curve 1 maximum input
-100.0~100.0
100.0
0.1%
C2.08
AI curve 2 minimum input
-10.00~C2.10
0.00
0.01V
C2.09
Corresponding setting of
AI curve 2 minimum input
-100.0~100.0
0.0
0.1%
C2.10
AI curve 2 maximum input
C2.08~10.00
10.00
0.01V
C2.11
Corresponding setting of
AI curve 2 maximum input
-100.0~100.0
100.0
0.1%
C2.12
AI curve 3 minimum input
-10.00~C2.14
0.00
0.01V
C2.13
Corresponding setting of
AI curve 3 minimum input
-100.0~100.0
0.0
0.1%
C2.14
AI curve 3 maximum input
C2.12~10.00
10.00
0.01V
C2.15
Corresponding setting of
AI curve 3 maximum input
-100.0~100.0
100.0
0.1%
C2.16
Jump point of AI1 input
corresponding setting
-100.0~100.0
0.0
0.1%
C2.17
Jump amplitude of AI1 input
corresponding setting
0.0~100.0
0.5
0.1%
C2.18
Jump point of AI2 input
corresponding setting
-100.0~100.0
0.0
0.1%
C2.19
Jump amplitude of AI2 input
corresponding setting
0.0~100.0
0.5
0.1%
C2.20
Jump point of AI3 input
corresponding setting
-100.0~100.0
0.0
0.1%
C2.21
Jump amplitude of AI3 input
corresponding setting
0.0~100.0
0.5
0.1%
