Canworld CDE360-2S0R7 - Group C3: Analog Output

CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-59-
Function
Code
Name
Range
Default
Step
Description
C2.22
Setting for AI less than
minimum input
000~111
000
1
0: corresponding to minimum setting
1: 0.0%
Unit's digit: AI1
Ten's digit: AI2
Hundred's digit: AI3
C3 Analog Output
Function
Code
Name
Range
Default
Step
Description
C3.00
AO1 filter time
0.00~10.00
0.00
0.01Sec
C3.01
AO2 filter time
0.00~10.00
0.00
0.01Sec
C3.02
AO1 function
0~17
1
1
0: Set frequency
1: Running frequency
2: Output current
3: Output voltage
4: Output power
5: Output torque
6: AI1
7: AI2
8: AI3
9: Pulse input( from X6/FI )
10: Target torque
11: PID setting
12: PID feedback
13: PID output
14: Actual length
15: Count value
16: Communication setting
17: Feedback speed
C3.03
AO2 function
0~17
2
1
Same As C3.02
C3.04
AO curve selection
11~22
21
1
1: AO curve 1
(C3.05~08)
2: AO curve 2
(C3.09~12)
Unit's digit: AO1
Ten's digit: AO2
C3.05
AO curve 1 minimum output
0.00~10.00
0.00
0.01V
C3.06
Corresponding setting of AO
curve 1 minimum output
0.0~C3.08
0.0
0.1%
C3.07
AO curve 1 maximum output
0.00~10.00
10.00
0.01V
C3.08
Corresponding setting of AO
curve 1 maximum output
C3.06~100.0
100.0
0.1%
C3.09
AO curve 2 minimum output
0.00~10.00
0.00
0.01V
C3.10
Corresponding setting of AO
curve 2 minimum output
0.0~C3.12
0.0
0.1%
C3.11
AO curve 2 maximum output
0.00~10.00
10.00
0.01V
C3.12
Corresponding setting of AO
curve 2 maximum output
C3.10~100.0
100.0
0.1%
