CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-75-
E7 Swing Frequency
Function
Code
Name
Range
Default
Step
Description
E7.00
Swing frequency
setting mode
0~1
0
1
0: reference to setting frequency
1: reference to max frequency
E7.01
Swing frequency
amplitude
0.0~100.0
0.0
0.1%
E7.02
Skip frequency
amplitude
0.0~50.0
0.0
0.1%
E7.03
Swing frequency
cycle
0.1~3000.0
10.0
0.1Sec
E7.04
Triangular wave
rising time
coefficient
0.1~99.9
50.0
0.1%
E7.05
Set count value
E7.06~65535
1000
1
E7.06
Designated
count value
1~E7.05
1000
1
E7.07
Set length
0~65535
1000
1m
E7.08
Number of
pulses per meter
0.1~6553.5
100.0
0.1
E8 Droop Control
Function
Code
Name
Range
Default
Step
Description
E8.00
Droop control
0.00~10.00
0.00
0.01Hz
E8.01
Droop control
filter time
0.00~60.00
0.00
0.01Sec
E9 Power Loss Ride Through
Function
Code
Name
Range
Default
Step
Description
E9.00
Action selection at power
loss ride through
0~1
0
1
0: Disabled
1: Enabled
E9.01
Action judging voltage at
power loss ride through
40.0~150.0
80.0
0.1%
E9.02
Action pause judging voltage
at power loss ride through
60.0~150.0
100.0
0.1%
E9.03
Voltage rally judging time at
power loss ride through
0.00~50.00
0.50
0.01
Sec
