CDE360 Vector Control AC Drive Chapter 4 Operation,Display and Application
-44-
4.8 User Defined Parameters
Please refer to the parameters description of group P0.
4.9 Non-basic Menu Display
Two non-basic menu is determined by H0.05, as shown in the table below.
Table 4- 5 Menu display types
H0.05
Menu display type
0
Basic menu. Displayed all parameters.
1
User-defined parameters. Display group P0 only.
2
Non factory setting parameters. Display the parameters
which have been modified.
For example
A. Steps of changing menu type from basic to user-defined.
1. Set H0.05=1.
2. Return Level 0 menu by pressing PRG key.
3. Press PRG again,and the keypad will go into user-defined parameters display
model.
B. Steps of going back to basic menu form user-defined.
1. Find and set H0.05=0.
2. Return Level 0 menu by pressing PRG key;
3. Press PRG again,and the keypad will go into basic parameters display model.
