CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
F1 Auto Reset
Time interval of fault auto reset
DO action during fault auto reset
Unit's digit: Fault indication terminals
0: No action during fault reset process
1: Action during fault reset
Ten's digit: restart after automatic fault reset
H0 System Parameters
LED display running
parameters 1
Bit0: Running frequency(1)
Bit1: Setting frequency(2)
Bit2: Dc-link voltage(4)
Bit3: Output current(8)
Bit4: Output voltage(16)
Bit5: Output torque(32)
Bit6: Output power(64)
Bit7: AI1 voltage(128)
Bit8: AI2 voltage(256)
Bit9: AI3 voltage(512)
Bit10: X terminals status(1024)
Bit11: Y terminals status(2048)
Bit12: PLC stage(4096)
Bit13: PID setting(8192)
Bit14: PID feedback(16384)
Bit15: Count value(32768)
LED display running
parameters 2
Bit0: FI input frequency(1)
Bit1: Linear speed(2)
Bit2: Load speed(4)
Bit3: Actual length(8)
Bit4: remaining running time(16)
Bit5: Main frequency A (32)
Bit7: FO output frequency(128)
Bit8:Feedback speed(256)
Bit9:motor speed(512)
Bit10:Multi-Pump Control status
words(1024)
LED display stop
parameters
Bit0: Setting frequency(1)
Bit1: Dc-link voltage(2)
Bit2: X terminals status(4)
Bit3: Y terminals status(8)
Bit4: AI1 voltage(16)
Bit5: AI2 voltage(32)
Bit6: AI3 voltage(64)
Bit7: FI input frequency(128)
Bit8: PID setting(256)
Bit9: PID feedback(512)
Bit10: PLC stage(1024)
Bit11: Pulse input frequency(2048)
Bit12: actual length(4096)
Bit13~Bit15: reserve
0: No Operation 1: Restore to factory default value, not include motor parameters
2: Restore to factory default value, including motor parameters
3: Parameter upload to keypad 4: Parameter download from keypad
0: Display all parameters 1: Display user-defined parameters
2: Display non factory setting parameters
