CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-60-
C4 Pulse Input/Output
Function
Code
Name
Range
Default
Step
Description
C4.00
FI filter time
0.00~10.00
0.10
0.01Sec
C4.01
FI minimum input
0.00~C4.03
0.00
0.01kHz
C4.02
Corresponding setting of FI
minimum input
-100.0~100.0
0.0
0.1%
C4.03
FI maximum input
C4.01~100.00
50.00
0.01kHz
C4.04
Corresponding setting of FI
maximum input
-100.0~100.0
100.0
0.1%
C4.05
FO filter time
0.00~10.00
0.00
0.01Sec
C4.06
FO function
0~17
1
1
Same As C3.02
C4.07
FO output minimum frequency
0.00~100.00
0.00
0.01kHz
C4.08
Corresponding setting of FO
output minimum frequency
0.0~C4.10
0.0
0.1%
C4.09
FO output maximum frequency
0.00~100.00
50.00
0.01kHz
C4.10
Corresponding setting of FO
output maximum frequency
C4.08~100.0
100.0
0.1%
C5 Virtual Digital Input/Output
Function
Code
Name
Range
Default
Step
Description
C5.00
①
VX1 function
0~58
0
1
Same As C0.01
C5.01
①
VX2 function
0~58
0
1
C5.02
①
VX3 function
0~58
0
1
C5.03
①
VX4 function
0~58
0
1
C5.04
VX active state mode
selection
0000~4444
1111
1
0: Set by VYn
1: Set by C5.05
2: Set by AI1
3: Set by AI2
4: Set by AI3
Unit's digit: VX1
Ten's digit: VX2
Hundred's digit: VX3
Thousand's digit: VX4
C5.05
Digital setting of VX
active state
0000~1111
0000
1
0: Active
1: Inactive
Unit's digit: VX1
Ten's digit: VX2
Hundred's digit: VX3
Thousand's digit: VX4
C5.06
①
Active mode for AI as
VX input
000~111
000
1
0: High is active
1: Low is active
Unit's digit: AI1
Ten's digit: AI2
Hundred's digit: AI3
C5.07
①
Active mode for AI as
VX input
C5.08~8.00
6.70
0.01V
C5.08
①
Active mode for AI as
VX input
1.00~C5.07
3.20
0.01V
