CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-52-
Function
Code
Name
Range
Default
Step
Description
b0.06
①
Motor rated power
0.1~999.9
Module
dependent
0.1kw
b0.07
①
Motor rated voltage
1~2000
Module
dependent
1V
b0.08
①
Motor rated current
0.01~655.35
0.01A
b0.09
①
Motor rated frequency
10.00~b0.00
50.00
0.01Hz
b0.10
①
Motor rated speed
1~65535
1460
1RPM
b0.11
Command Source
0~2
0
1
0: Keypad
1: I/O terminal
2: Communication
b0.12
①
Application setting
0~13
0
1
0: General
1: PID application
2: Constant pressure water supply of one AC drive with two pumps
3~13: Reserved
b1 Run & Stop logic
Function
Code
Name
Range
Default
Step
Description
b1.00
①
Acceleration/Deceleration
mode
0~1
0
1
0: Linear
1: S Curve
b1.01
①
Time proportion of S-curve
start segment
0.0~(100.0-
b1.02)
30.0
0.1%
b1.02
①
Time proportion of S-curve
end segment
0.0~(100.0-
b1.01)
30.0
0.1%
b1.03
Startup frequency
0.00~50.00
0.00
0.01Hz
b1.04
①
Startup frequency holding
time
0.0~100.0
0.0
0.1Sec
b1.05
Start mode
0~1
0
1
0: Ramp start from startup frequency
1: Flying start
b1.06
①
Flying start mode
0~2
0
1
0: From frequency at stop
1: From zero speed
2: From maximum frequency
b1.07
①
Flying start current
50.0~200.0
90.0
0.1%
The current limit value of
flying start process
b1.08
flying start speed
1~100
5
1
b1.09
①
V/f coefficient for flying start
30.0~100.0
100.0
0.1%
b1.10
Stop mode
0~1
0
1
0: Ramp stop
1: Coasting stop
b1.11
①
Start DC brake current
0~100
20
1%
b1.12
①
Start DC brake time
0.0~100.0
0.0
0.1Sec
b1.13
Initial frequency of stop DC
brake
0.00~b0.00
0.00
0.01Hz
