Canworld CDE360-2S0R7 - E6 Multi-Pump Control

CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-74-
E6 Multi-Pump Control
Function
Code
Name
Range
Default
Step
Description
E6.00
①
Multi-pump control mode
0~4
0
1
This series AC drive support multi pump control modes. Each of them is apply to different application area
with specific configuration and operation logic. 0: Inactive
1: Frequency pump fixed, No auto change
2: Frequency pump fixed, Support auto change
3: Frequency pump circulation, No auto change
4: Frequency pump circulation, Support auto change
E6.01
Number of motors
1~4
1
1
E6.02
Reference step 1
0.0~100.0
0.0
0.1%
Active if one auxiliary motor at lease is running.Its base value is current PID reference.
E6.03
Reference step 2
0.0~100.0
0.0
0.1%
Active if two auxiliary motors at lease are running.Its base value is current PID reference.
E6.04
Reference step 3
0.0~100.0
0.0
0.1%
Active if Three auxiliary motors at lease are running.Its base value is current PID reference.
E6.05
interlock functions
00~11
00
1
Interlock function is used to indicate whether each motor is connected to multi pump control logic or not.
Unit's digit: interlock enable
0: disabled
1: enabled
Ten's digit: interlcok mode
0: decided by X terminals
1: decided by E6.06
E6.06
Digital setting of motor interlock
0000~1111
0000
1
0: Not connected to multi-pump system
1: Connected to multi-pump system
Unit's digit: Motor 1#
Ten's digit: Motor 2#
Hundred's digit:Motor 3#
Thousand's digit:Motor 4#
E6.07
Auto-change interval
0.1~6000.0
48.0
0.1h
E6.08
Auto-change frequency limit
0.00~b0.00
45.00
0.01Hz
E6.09
Auto-change motor limit
1~3
1
1
E6.10
Add pump frequency 1
0.00~b0.00
48.00
0.01Hz
E6.11
Reduce pump frequency 1
0.00~E6.10
25.00
0.01Hz
E6.12
Add pump frequency 2
0.00~b0.00
48.00
0.01Hz
E6.13
Reduce pump frequency 2
0.00~E6.12
25.00
0.01Hz
E6.14
Add pump frequency 3
0.00~b0.00
48.00
0.01Hz
E6.15
Reduce pump frequency 3
0.00~E6.14
25.00
0.01Hz
E6.16
Add pump delay time
0.0~3600.0
5.0
0.1Sec
E6.17
Dec pump delay time
0.0~3600.0
3.0
0.1Sec
E6.18
Electromagnetic switch delay
time
0.00~10.00
0.20
0.01Sec
E6.19
Switch over frequency from AC
drive to grid
0.00~b0.00
50.00
0.01Hz
