Canworld CDE360-2S0R7 - F0 Protection

CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-78-
F0 Protection
Function
Code
Name
Range
Default
Step
Description
F0.00
Under voltage threshold
Module
dependent
Module
dependent
0.1V
F0.01
①
Over voltage threshold
Module
dependent
Module
dependent
0.1V
F0.02
Input phase loss protection
0~1
1
1
0: Disabled
1: Enabled
F0.03
Output phase loss protection
0~1
1
1
0: Disabled
1: Enabled
F0.04
Short-circuit to ground upon
power-on
0~1
0
1
0: Disabled
1: Enabled
F0.05
AC drive over load protection gain
0.30~3.00
1.00
0.01
F0.06
Motor overload protection
0~1
1
1
0: Disabled
1: Enabled
F0.07
Motor overload protection gain
0.20~10.00
1.00
0.01
F0.08
Motor overload warning coefficient
50~100
80
1%
F0.09
Under load protection
0~1
0
1
0: Disabled
1: Enabled
F0.10
Detection level of Under load
0.0~100.0
40.0
0.1%
F0.11
Detection time of Under load
0.0~60.0
1.0
0.1Sec
F0.12
Motor temperature sensor type
0~2
0
1
0: No sensor
1: PT100
2: PT1000
F0.13
Motor overheat protection threshold
0.0~200.0
120.0
0.1℃
F0.14
Motor overheat warning threshold
0.0~200.0
100.0
0.1℃
F0.15
Over-speed detection value
0.0~50.0
20.0
0.1%
F0.16
Over-speed detection time
0.0~60.0
5.0
0.1Sec
F0.17
Detection value of too large speed
deviation
0.0~50.0
20.0
0.1%
F0.18
Detection time of too large speed
deviation
0.0~60.0
1.0
0.1Sec
F0.19
Fault protection action selection 1
0000~2222
0000
1
Unit's digit: input phase loss
0: Coasting stop
1: stop by stop mode
2: continue running
Ten's digit: output phase loss（same as unit's digit）
Hundred's digit: AC drive overload（same as unit's digit）
Thousand's digit: Motor overload（same as unit's digit）
