CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-67-
Function
Code
Name
Range
Default
Step
Description
d5.14
①
Motor 2 weaken flux
coefficient 2
0.000~1.000
1.000
0.001
Flux weakening
coefficient at 50%
flux current
d5.15
①
Motor 2 weaken flux
coefficient 3
0.000~1.000
1.000
0.001
Flux weakening
coefficient at 80%
flux current
d5.22
①
Motor 2 auto tune
0~2
0
1
0: No action
1: Static auto tune
2: rotational auto tune
d6 Motor 2 Speed Control
Function
Code
Name
Range
Default
Step
Description
d6.00
Motor 2 ASR
proportional gain Kp1
1~100
30
1
d6.01
Motor 2 ASR integration
time Ti1
0.01~10.00
0.50
0.01Sec
d6.02
Motor 2 ASR
proportional gain Kp2
1~100
20
1
d6.03
Motor 2 ASR integration
time Ti2
0.01~10.00
1.00
0.01Sec
d6.04
Motor 2 Low speed
switchover frequency
0.00~d6.05
5.00
0.01Hz
d6.05
Motor 2 High speed
switchover frequency
d6.04~b0.00
10.00
0.01Hz
d6.06
Motor 2 ASR integration
attribute
0~1
0
1
Same As d2.06
d6.07
Motor 2 Vector control
slip gain
50~200
100
1%
d6.08
Motor 2 ASR filter time
0~1023
0
1
d6.09
Motor 2 Upper torque
limit Source of forward
motoring
0~7
0
1
0: d6.10
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d6.10
Motor 2 Preset upper
torque limit of forward
motoring
0.0~300.0
150.0
0.1%
