CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-72-
E5 PID
Function
Code
Name
Range
Default
Step
Description
E5.00
①
PID engineering unit
0~5
0
1
0:Percentage(%)
1:Pressure(MPa)
2:Centigrade(℃)
3:Kilowatt(kW)
4:Kilowatt hour(kWh)
5:Flow(m
3
/h)
E5.01
PID engineering unit resolution
0~3
1
1
0: No decimal
1: One decimal
2: Two decimals
3: Three decimals
E5.02
Maximum setting of PID
engineering unit
E5.03
~6553.5
100.0
0.1%
Unit/Decimal depends
on E5.00/E5.01.
First set E5.02, then
set E5.03.
E5.03
Minimum setting of PID
engineering unit
0.0~E5.02
0.0
0.1%
E5.04
PID setting source
0~6
0
1
0: E5.05+UP/DOWN
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Multi-Reference
6: Communication
E5.05
PID digital setting
E5.03~E5.02
50.0
0.1%
Unit/Decimal depends
on E5.00/E5.01.
E5.06
PID setting changing time
0.00~99.99
0.00
0.01Sec
E5.07
PID feedback source
0~8
0
1
0: AI1
2: AI3
4: X6/FI
6: MAX(|AI1|,|AI2|)
8: Communication
1: AI2
3: AI1-AI2
5: AI1+AI2
7: MIN(|AI1|,|AI2|)
E5.08
PID feedback filter time
0.00~60.00
0.00
0.01Sec
E5.09
PID proportion gain Kp1
0.0~999.9
2.0
0.1%
E5.10
PID integral time Ti1
0.01~99.99
0.50
0.01Sec
E5.11
PID differential time Td1
0.000~9.999
0.000
0.001Sec
E5.12
PID proportion gain Kp2
0.0~999.9
50.0
0.1
E5.13
PID integral time Ti2
0.01~99.99
2.00
0.01
E5.14
PID differential time Td2
0.000~9.999
0.000
0.001
E5.15
PID parameter switchover condition
0~2
0
1
0: No switchover
1: Switchover via X terminals
2: Automatic switchover based on deviation
E5.16
PID parameter switchover deviation 1
E5.03~E5.17
20.0
0.1%
Unit/Decimal depends
on E5.00/E5.01.
E5.17
PID parameter switchover deviation 2
E5.16~E5.02
80.0
0.1%
E5.18
PID output initial value
0.0~100.0
0.0
0.1%
E5.19
PID output initial value holding time
0.00~600.00
0.00
0.01Sec
E5.20
PID output filter time
0.00~60.00
0.00
0.01Sec
E5.21
①
PID action direction
0~1
0
1
0:Positive 1:Negative
E5.22
PID differential limit
0.0~100.0
0.5
0.1%
E5.23
Maximum deviation between two
PID outputs in forward direction
0.00~99.99
1.00
0.01%
E5.24
Maximum deviation between two
PID outputs in reverse direction
0.00~99.99
1.00
0.01%
