CDE360 Vector Control AC Drive Chapter 10 Optional Cards
248
10.3 Multi-function IO Card（IO3）
IO3 is an optional card for digital input and relay output.It needs to be used together with the
vector control AC drives which is produced by our company.
 Functional overview
 4 digital inputs（X7~X10）
 2 relay outputs（T3~T4）
 24V supply for external use
 Pin description
Table 10-3 Optional card IO3
Terminal Symbol
Description
X7
Digital input 7
X8
Digital input 8
X9
Digital input 9
X10
Digital input10
CMX1
X7~X10 common port
+24V
24V supply
COM
Ground of 24V
T3-A
Relay 3 common port
T3-C
Relay 3 normally open port
T4-A
Relay 4 common port
T4-C
Relay 4 normally open port
Note:
1）X7~X10 function is the same with X terminal function of control board.
2）T3~T4 function is the same with T terminal function of control board.
3）24V is the same with 24V terminal of control board.
 Installation of the optional card
Please see the figure 10-1.
