CDE360 Vector Control AC Drive Chapter 2 Product Information
2.3 CDE360 Nameplate
Figure 2- 2 Nameplate
2.4 CDE360 Model and Technical Parameters
2.4.1 General Series
1） 2S class (single-phase 220V AC input)
Table 2- 2 CDE360-2S class model and technical parameters
AC drive model
CDE360-
Power
capacity
（KVA）
Input
current（A）
Output
current
（A）
Brake unit
DC
reactor
Keypad
2S0R7
1.5
8.2
4
Built-in
(Optional)
Not
installed
LED
(Standard)
键盘
2S1R5
3
14
7
Remarks:
1) The models in the table above do not have input phase loss protection.
2) The models in the table above are single and wall-mounted type.
