Canworld CDE360-2S0R7 - Group d0: Motor Control

CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-61-
Function
Code
Name
Range
Default
Step
Description
C5.09
①
VY1 function
0~45
0
1
Same As C1.01
C5.10
①
VY2 function
0~45
0
1
Same As C1.01
C5.11
①
VY3 function
0~45
0
1
Same As C1.01
C5.12
①
VY4 function
0~45
0
1
Same As C1.01
C5.13
VY1 output delay time
0.0~3600.0
0.0
0.1Sec
C5.14
VY2 output delay time
0.0~3600.0
0.0
0.1Sec
C5.15
VY3 output delay time
0.0~3600.0
0.0
0.1Sec
C5.16
VY4 output delay time
0.0~3600.0
0.0
0.1Sec
C5.17
VY terminal active
state logic
0000~1111
0000
1
0: Positive logic
1: Negative logic
Unit's digit: VY1
Ten's digit: VY2
Hundred's digit: VY3
Thousand's digit: VY4
d0 Motor Control
Function
Code
Name
Range
Default
Step
Description
d0.00
①
Motor control mode
0~2
0
1
0: V/f
1: Open loop vector control
2: Close loop vector control
d0.01
Carrier frequency
Module
dependent
Module
dependent
0.1kHz
d0.02
Carrier frequency
adjustment with
temperature
0~1
1
1
0: Enabled
1: Disabled
d0.03
Random PWM depth
0~10
0
1
Random PWM can decrease motor noise without increasing carrier frequency. The bigger , the wider spectrum.
0: disable random PWM
1~10: setting the depth of random PWM
d0.04
DPWM switchover
frequency upper limit
0.00~b0.00
10.00
0.01Hz
If the output frequency is higher than this Value + 3Hz, the DPWM modulation mode is adopted, or else
continuous method is adopted.
d0.05
PWM Modulation
mode
0~1
0
1
0: Asynchronous modulation
1: Synchronous modulation
d0.06
Torque boost
0.0~20.0
Module
dependent
0.1%
0.0%: auto torque boost
> 0.0%: customized
torque boost
d0.07
①
Cut-off frequency of
torque boost
0.00~b0.00
37.00
0.01Hz
