CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-70-
E3 Simple PLC
Function
Code
Name
Range
Default
Step
Description
E3.00
Simple PLC running mode
0~2
0
1
0: Stop after the AC drive running one cycle
1: Keep final values after the AC drive running one cycle
2: Repeat after the AC drive running one cycle
E3.01
Simple PLC retentive selection
00~11
00
1
Unit's digit (Retentive upon power failure) 0: No 1: Yes
Ten's digit (Retentive upon stop) 0: No 1: Yes
E3.02
Time unit of simple PLC running
0~1
0
1
0: Sec (second)
1: h (hour)
E3.03
Running time of simple PLC
reference 0
0.0~6553.5
0.0
0.1Sec
E3.04
Acc/dec time of simple PLC
reference 0
0~3
0
1
0: Acceleration/deceleration time 1
1: Acceleration/deceleration time 2
2: Acceleration/deceleration time 3
3: Acceleration/deceleration time 4
E3.05
Running time of simple PLC reference 1
0.0~6553.5
0.0
0.1Sec
E3.06
Acc/dec time of simple PLC reference 1
0~3
0
1
Same As E3.04
E3.07
Running time of simple PLC reference 2
0.0~6553.5
0.0
0.1Sec
E3.08
Acc/dec time of simple PLC reference 2
0~3
0
1
Same As E3.04
E3.09
Running time of simple PLC reference 3
0.0~6553.5
0.0
0.1Sec
E3.10
Acc/dec time of simple PLC reference 3
0~3
0
1
Same As E3.04
E3.11
Running time of simple PLC reference 4
0.0~6553.5
0.0
0.1Sec
E3.12
Acc/dec time of simple PLC reference 4
0~3
0
1
Same As E3.04
E3.13
Running time of simple PLC reference 5
0.0~6553.5
0.0
0.1Sec
E3.14
Acc/dec time of simple PLC reference 5
0~3
0
1
Same As E3.04
E3.15
Running time of simple PLC reference 6
0.0~6553.5
0.0
0.1Sec
E3.16
Acc/dec time of simple PLC reference 6
0~3
0
1
Same As E3.04
E3.17
Running time of simple PLC reference 7
0.0~6553.5
0.0
0.1Sec
E3.18
Acc/dec time of simple PLC reference 7
0~3
0
1
Same As E3.04
E3.19
Running time of simple PLC reference 8
0.0~6553.5
0.0
0.1Sec
E3.20
Acc/dec time of simple PLC reference 8
0~3
0
1
Same As E3.04
E3.21
Running time of simple PLC reference 9
0.0~6553.5
0.0
0.1Sec
E3.22
Acc/dec time of simple PLC reference 9
0~3
0
1
Same As E3.04
E3.23
Running time of simple PLC reference 10
0.0~6553.5
0.0
0.1Sec
E3.24
Acc/dec time of simple PLC reference 10
0~3
0
1
Same As E3.04
E3.25
Running time of simple PLC reference 11
0.0~6553.5
0.0
0.1Sec
E3.26
Acc/dec time of simple PLC reference 11
0~3
0
1
Same As E3.04
