d3 Torque Control
Function
Code
Name
Range
Default
Step
Description
d3.00
①
Speed/Torque control
selection
0~1
0
1
0: Speed Control
1: Torque Control
d3.01
①
Torque reference
source
0~7
0
1
0: d3.02+UP/DOWN
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d3.02
Digital setting of
torque reference
-300.0~300.0
150.0
0.1%
d3.03
①
Torque compensation
source
0~7
0
1
0: d3.04
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d3.04
Digital setting of
torque compensation
-300.0~300.0
0.0
0.1%
d3.05
①
Speed limit mode
0~5
0
1
0: Minimum frequency to maximum frequency
1: Minimum frequency to running frequency
2: Negative running frequency to positive running frequency
3: Running frequency to maximum frequency
4: Running frequency + windows
5: 0Hz to output frequency
d3.06
①
maximum frequency
source
0~7
0
1
0: d3.07
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d3.07
Digital setting of
Maximum frequency
-b0.00~b0.00
50.00
0.01Hz
d3.08
①
Minimum frequency
source
0~7
0
1
0: d3.09
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d3.09
Digital setting of
minimum frequency
-b0.00~b0.00
-50.00
0.01Hz
d3.10
Window positive error
0.00~50.00
5.00
0.01Hz
d3.11
Window negative
error
-50.00~0.00
-5.00
0.01Hz
d3.12
Static torque
compensation
0.0~100.0
0.0
0.1%
