CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-64-
Function
Code
Name
Range
Default
Step
Description
d2.09
Upper torque limit Source of
forward motoring
0~7
0
1
0: d2.10
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d2.10
Preset upper torque limit of
forward motoring
0.0~300.0
150.0
0.1%
d2.11
Upper torque limit Source of
reverse motoring
0~7
0
1
0: d2.12
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d2.12
Preset upper torque limit of
reverse motoring
0.0~300.0
150.0
0.1%
d2.13
Upper torque limit Source of
forward generating
0~7
0
1
0: d2.14
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d2.14
Preset upper torque limit of
forward generating
0.0~300.0
150.0
0.1%
d2.15
Upper torque limit Source of
reverse generating
0~7
0
1
0: d2.16
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d2.16
Preset upper torque limit of
reverse generating
0.0~300.0
150.0
0.1%
d2.17
proportional gain of flux
current loop
0~30000
2000
1
d2.18
integration time of flux current
loop
0~30000
800
1
d2.19
proportional gain of torque
current loop
0~30000
2000
1
d2.20
integration time of torque
current loop
0~30000
400
1
d2.21
①
Vector control optimization
mode
000~111
110
1
0: Disabled
1: Enabled
Unit's digit :
Loop control optimization
Ten's digit:
Angle estimation optimization
Hundred's digit:
Low frequency torque optimization
