CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-53-
Function
Code
Name
Range
Default
Step
Description
b1.14
Stop DC brake waiting time
0.0~100.0
0.0
0.1Sec
b1.15
Stop DC brake current
0~100
20
1%
b1.16
Stop DC brake time
0.0~100.0
0.0
0.1Sec
b1.17
Running mode when
running frequency lower
than frequency lower limit
0~3
0
1
0: Run at frequency lower limit
1: Run at zero speed
2: Stop
3: Stop, restart when setting frequency higher than lower limit
b1.18
Running direction
0~1
0
1
0: Same direction
1: Reverse direction
It is used to set the motor direction which is consistent with the reference frequency or not, whatever the
control source is.
b1.19
Forward/Reverse rotation
dead-zone time
0.0~3000.0
0.0
0.1Sec
b1.20
Reverse prohibition
0~1
0
1
0: Reverse enabled
1: Reverse disabled
b1.21
Stop key function
0~1
1
1
0: STOP/RESET key enabled only in operation keypad control
1: STOP/RESET key enabled in any operation mode
b1.22
Startup protection
0~1
1
1
0: No 1: Yes
If this parameter is set to 1, even the start command is active, the AC drive will be not response to the start command. Users
should cancel the start command firstly, then send the start command again to run the AC drive.
b1.23
Dynamic brake
use ratio
0~100
100
1%
The larger the value of this parameter is, the larger braking duty will be. 0% means disable dynamic brake function.
b1.24
Dynamic brake
voltage
Module
dependent
Module
dependent
0.1V
b1.25
①
Multi function
of JOG key
0~2
0
1
For function selection of JOG key on
Keypad.
0: JOG
1:Forward/Reverse switching
2:Command source switching
b2 Frequency Source
Function
Code
Name
Range
Default
Step
Description
b2.00
①
Main frequency
source A
0~8
0
1
0: b2.01+UP/DOWN
1: AI1
2: AI2
3: AI3
4: X6/FI
5: PID
6: PLC
7: Multi-Reference
8: Communication
