CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-51-
Function
Code
Name
Range
Default
Step
Description
A1.22
Accumulative running day upon 2nd
fault
0~9999
0
1Day
A1.23
Accumulative running hour upon 2nd
fault
0.00~23.99
0.00
0.01h
A1.24
3rd fault type
0~54
0
1
Same As
A1.00~A1.11
A1.25
Output frequency upon 3rd fault
0.00~b0.00
0.00
0.01Hz
A1.26
Output current upon 3rd fault
0.00~655.35
0.00
0.01A
A1.27
DC bus voltage upon 3rd fault
0.0~6553.5
0.0
0.1V
A1.28
X terminals status word upon 3rd fault
0~1023
0
1
A1.29
Y terminals status word upon 3rd fault
0~511
0
1
A1.30
AC drive status word upon 3rd fault
0~65535
0
1
A1.31
Inverter module temperature upon 3rd
fault
-40.0~125.0
0.0
0.1℃
A1.32
Power-on time upon 3rd fault
0~65535
0
1Min
A1.33
Running time upon 3rd fault
0.0~6553.5
0.0
0.1Min
A1.34
Accumulative running day upon 3rd
fault
0~9999
0
1Day
A1.35
Accumulative running hour upon 3rd
fault
0.00~23.99
0.00
0.01h
b0 Basic Parameters
Function
Code
Name
Range
Default
Step
Description
b0.00
①
Max frequency
30.00~600.00
50.00
0.01Hz
This parameter define
the Max allowable
output frequency.
b0.01
①
Source of Upper limit
frequency
0~5
0
1
0: b0.02
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
b0.02
Digital setting of upper
limit frequency
b0.03~b0.00
50.00
0.01Hz
b0.03
Lower limit frequency
0.00~b0.02
0.00
0.01Hz
b0.04
Acceleration time 1
0.1~6000.0
Module
dependent
0.1Sec
b0.05
Deceleration time 1
0.1~6000.0
Module
dependent
0.1Sec
