CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-71-
Function
Code
Name
Range
Default
Step
Description
E3.27
Running time of simple PLC reference 12
0.0~6553.5
0.0
0.1Sec
E3.28
Acc/dec time of simple PLC reference 12
0~3
0
1
Same As E3.04
E3.29
Running time of simple PLC reference 13
0.0~6553.5
0.0
0.1Sec
E3.30
Acc/dec time of simple PLC reference 13
0~3
0
1
Same As E3.04
E3.31
Running time of simple PLC reference 14
0.0~6553.5
0.0
0.1Sec
E3.32
Acc/dec time of simple PLC reference 14
0~3
0
1
Same As E3.04
E3.33
Running time of simple PLC reference 15
0.0~6553.5
0.0
0.1Sec
E3.34
Acc/dec time of simple PLC reference 15
0~3
0
1
Same As E3.04
E4 Acc & Dec Time
Function
Code
Name
Range
Default
Step
Description
E4.00
acceleration time 2
0.1~6000.0
Module
dependent
0.1Sec
E4.01
deceleration time 2
0.1~6000.0
0.1Sec
E4.02
acceleration time 3
0.1~6000.0
Module
dependent
0.1Sec
E4.03
deceleration time 3
0.1~6000.0
Module
dependent
0.1Sec
E4.04
acceleration time 4
0.1~6000.0
Module
dependent
0.1Sec
E4.05
deceleration time 4
0.1~6000.0
Module
dependent
0.1Sec
E4.06
Frequency switchover
point between
acceleration time 1&2
0.00~b0.00
0.00
0.01Hz
E4.07
Frequency switchover
point between
deceleration time 1&2
0.00~b0.00
0.00
0.01Hz
E4.08
①
Acceleration/
Deceleration time unit
0~2
1
1
0: 1 Sec
1: 0.1 Sec
2: 0.01 Sec
E4.09
①
Reference frequency of
Acceleration/
Deceleration time
0~2
0
1
Acceleration/
Deceleration time is
defined as the time
between 0Hz to E4.09
0: Max frequency(b0.00)
1: Current setting frequency
2: 100Hz
