CDE360 Vector Control AC Drive Chapter 4 Operation,Display and Application
-40-
4.4 Keypad Display
LED screen can only display 4 digits. If the parameter value is more than 4 digits, the display
method is shown in the table below.
Note: If the parameter can be modified, each digit can be switched by SHIFT key.
Table 4- 3 Five digits shown method of LED screen
Actual value
Display value
After press the SHIFT key
12345
1234.
2345
1234.5
1234
234.5
123.45
123.4
23.45
12.345
12.34
2.345
0.1234
0.123
1234
0.0034
0.003
0034
0.0004
0.000
0004
Common LDE display sign.
Table 4- 4 Common LDE display sign
Sign
Meaning
8.8.8.8.
AC drive is in initialization after power on.
LCD screen shows non character.
dEFt
Being restoring default settings of the parameters.
LCD screen will show ‘Restoring default setting’.
Load
Being uploading the parameters. LCD screen will show
‘Uploading’.Please wait for a few minutes.
Copy
Being downloading the parameters. LCD screen will
show ‘Downloading’.Please wait for a few minutes.
TUNE
The motor parameters is being auto-tuning.
LCD screen will show ‘Motor Auto-tuning’. Please wait
for a few minutes.
P.SEt
User password is set successfully.
P.CLr
User password is cleared successfully.
Tips:
The Keypad with LCD screen can display two monitor parameters at the same time.
 LCD screen can display 2 lines of characters.
 Move the cursor to first line on LCD screen, press SHIFT key to select the first monitor
parameter.
 Press ENTER key the move the cursor the second line,press SHIFT key to select the
second monitor parameter.
