CDE360 Vector Control AC Drive Chapter 2 Product Information
Figure 2- 6 The foundation of KEYB
2.6.6 Dust Excluding Plate A
Used for the AC drive of W01 type appearance. Standard configuration is only one plate.Optional for
the requirements of both sides. The physical appearance and dimensions are shown in the following
figure.
Figure 2- 7 Dust excluding plate A
2.6.7 Dust Excluding Plate B
Used for the AC drive of W02 type appearance. Standard configuration is only one plate.Optional for
the requirements of both sides. The physical appearance and dimensions are shown in the following
figure.
Mounting size
