CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-46-
Parameter List Table
A0 Monitor
Function
Code
Name
Range
Default
Step
Description
A0.00
Running
frequency
0.00~b0.00
0.00
0.01Hz
A0.01
Setting frequency
0.00~b0.00
0.00
0.01Hz
A0.02
DC bus voltage
0.0~3000.0
0.0
0.1V
A0.03
Output voltage
0~1500
0
1V
A0.04
Output current
0.00~655.35
0.00
0.01A
Fraction point decided by AC
drive type
A0.05
Output torque
-300.0~300.0
0.0
0.1%
Unit is percentage. Base value
is motor rated torque
A0.06
Output power
0.0~2000.0
0.0
0.1kw
AC drive output active power
A0.07
Motor speed
0~65535
0
1RPM
A0.08
Main frequency A
0.00~b0.00
0.00
0.01Hz
A0.09
Auxiliary
frequency B
0.00~b0.00
0.00
0.01Hz
A0.10
AC drive status
word
0~65535
0
1
Bit0: ready
Bit1: running
Bit2: fault
Bit3: warning
Bit4: running direction
Bit6/Bit5: control source
Bit7: run Enable
Bit8: bypass
Bit9: frequency reached
Bit11/Bit10: Acc/Dec status
Bit12: JOG running
Bit13: auto tuning
Bit14: Zero speed
Bit15: RSERVED
A0.11
AI1 Voltage
-10.00~10.00
0.00
0.01V
Current signal needs to be
changed as voltage signal.
0mA equals to 0V, 20mA
equals to10V.
A0.12
AI2 Voltage
-10.00~10.00
0.00
0.01V
A0.13
AI3 Voltage
-10.00~10.00
0.00
0.01V
A0.14
AO1 voltage
0.00~10.00
0.00
0.01V
A0.15
AO2 voltage
0.00~10.00
0.00
0.01V
A0.16
X terminals
status word
0~1023
0
1
One bit corresponds one terminal status: 0: inactive 1: active
Bit0: X1 (1)
Bit1: X2 (2)
Bit2: X3 (4)
Bit3: X4 (8)
Bit4: X5 (16)
Bit5: X6 (32)
Bit6: X7（64）
Bit7: X8（128）
Bit8: X9（256）
Bit9: X10（512）
A0.17
Y terminals
status word
0~511
0
1
One bit corresponds one terminal status: 0: inactive 1: active
Bit0: Y1（1）
Bit1: Y2（2）
Bit2: Y3（4）
Bit3: T1（8）
Bit4: T2（16）
Bit5: T3（32）
Bit6: T4（64）
Bit7: T5（128）
Bit8: T6（256）
