CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-47-
Function
Code
Name
Range
Default
Step
Description
A0.18
FI frequency
0.00~100.00
0.00
0.01kHz
Display the X6/FI frequency
A0.19
FO frequency
0.00~100.00
0.00
0.01kHz
Display the Y2/FO high speed
pulse output frequency
A0.20
PID reference
0.0~100.0
0.0
0.1%
Its unit and decimal are
depended on engineering unit.
A0.21
PID feedback
0.0~100.0
0.0
0.1%
A0.22
PID deviation
-100.0~100.0
0.0
0.1%
A0.23
PID output
-100.0~100.0
0.0
0.1%
A0.24
PLC stage
0~15
0
1
A0.25
Pulse counter
0~65535
0
1
A0.26
Actual length
0~65535
0
1m
Dividing the number of pulses
by E7.08.
A0.27
Linear speed
0.0~6553.5
0.0
0.1m/Min
This parameter shows the
linear speed and its unit is
m/Min
A0.28
Remaining time
0.0~6553.5
0.0
0.1Min
This parameters will show the
remaining time when the
timing function is enabled.
A0.29
Swing center
frequency
0.00~b0.00
0.00
0.01Hz
It is decided by the current
frequency source. And it
shows the center frequency of
swing frequency function.
A0.30
Load speed
0~65535
0
1
Output frequency multiplied by
H0.08.
A0.31
Feedback speed
0~b0.00
0.00
0.01Hz
Showing the actual output
frequency.
A0.32
Multi pump
status word
0000~4444
0000
1
This parameter is used to
indicate the status of each
motor in multi-pump operation
process.
0: in interlock or not used
1: ready
2: wait for switching
3: connect to power grid
4: connect to AC drive
Unit's digit:: 1# pump status
Ten's digit:: 2# pump status
Hundred's digit:: 3# pump status
Thousand's digit: 4# pump status
