CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-82-
H1 AI/AO Calibration
Function
Code
Name
Range
Default
Step
Description
H1.00
AI1 actual voltage 1
0.500~4.000
Factory setting
0.001V
H1.01
AI1 display voltage 1
0.500~4.000
Factory setting
0.001V
H1.02
AI1 actual voltage 2
6.000~9.999
Factory setting
0.001V
H1.03
AI1 display voltage 2
6.000~9.999
Factory setting
0.001V
H1.04
AI2 actual voltage 1
0.500~4.000
Factory setting
0.001V
H1.05
AI2 display voltage 1
0.500~4.000
Factory setting
0.001V
H1.06
AI2 actual voltage 2
6.000~9.999
Factory setting
0.001V
H1.07
AI2 display voltage 2
6.000~9.999
Factory setting
0.001V
H1.08
AI3 actual voltage 1
0.500~4.000
Factory setting
0.001V
H1.09
AI3 display voltage 1
0.500~4.000
Factory setting
0.001V
H1.10
AI3 actual voltage 2
6.000~9.999
Factory setting
0.001V
H1.11
AI3 display voltage 2
6.000~9.999
Factory setting
0.001V
H1.12
AO1 display voltage 1
0.500~4.000
Factory setting
0.001V
H1.13
AO1 actual voltage 1
0.500~4.000
Factory setting
0.001V
H1.14
AO1 display voltage 2
6.000~9.999
Factory setting
0.001V
H1.15
AO1 actual voltage 2
6.000~9.999
Factory setting
0.001V
H1.16
AO2 display voltage 1
0.500~4.000
Factory setting
0.001V
H1.17
AO2 actual voltage 1
0.500~4.000
Factory setting
0.001V
H1.18
AO2 display voltage 2
6.000~9.999
Factory setting
0.001V
H1.19
AO2 actual voltage 2
6.000~9.999
Factory setting
0.001V
L0 Communication Setting
Function
Code
Name
Range
Default
Step
Description
L0.00
Baud rate
0~4
1
1
0: 4800 bps
1: 9600 bps
2: 19200 bps
3: 38400 bps
4: 57600 bps
L0.01
Data format
0~3
0
1
0: No check, data format <8,N,1>
1: No check, data format <8,N,2>
2: Even parity check, data format <8,E,1>
3: Odd parity check, data format <8,O,1>
L0.02
Slave address
1~247
1
1
L0.03
Response delay
0~20
2
1mSec
L0.04
Communication
timeout detection
time
0.0~60.0
0.0
0.1Sec
Zero means no
timeout detection.
