CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-81-
Code
Name
Range
Default
Step
Description
H0.06
Function code lock
0~1
0
1
0:Disabled 1:Enabled
H0.07
Accumulative power
on time lock password
0~9999
0
1
H0.08
Load speed display coefficient
0.001~9.999
0.300
0.001
H0.09
Load speed display
decimal digits
0~3
1
1
H0.10
①
G/L setting
0~1
0
1
0: G type 1: L type
H0.11
①
Fan control
0~2
0
1
0: Automatic run
1: Run after power on
2: Temperature control
H0.12
Dead zone compensation
mode selection
0~3
1
1
0: No compensation
1: Rectangle compensation
2: Trapezoid compensation
3: Trapezoid at Low frequency and rectangle at high frequency
H0.13
①
Dead zone compensation size
1~2048
1024
1
H0.14
①
Angle size when current
across zero
1~3640
Module
dependent
1
H0.15
①
Dead zone compensation
filter cut off frequency 1
0.10~300.00
50.00
0.01Hz
H0.16
①
Dead zone compensation
filter cut off frequency 2
0.10~300.00
200.00
0.01Hz
H0.17
①
Dead zone compensation
switchover frequency 1
0.10~H0.18
5.00
0.01Hz
H0.18
①
Dead zone compensation
switchover frequency 2
H0.17~b0.00
50.00
0.01Hz
H0.19
①
Optional card selection
0~11
0
1
0: no optional card
1: IO1(Y3,T3~T6 of normally open)
2: IO2(AI3,Y3, X7~X10)
3: IO3(X7~X10,T3~T4 of normally open)
4: IO4(PT100, PT1000)
5: PG1(ABZ differential type,optional 5V/12V)
6: PG2(ABZ OC & Push-pull type,optional
5V/12V/24V)
7: COM1(RS485+Modbus RTU,AI3,Y3,X7~X8)
8: COM2(Profibus)
9: COM3(CANopen)
10: COM4(GPRS)
11: COM5(Modbus TCP)
H0.20
Product series
0~999
Module
dependent
Factory
setting
1
H0.21
Function firmware version
0.00~99.99
0.01
H0.22
Algorithm firmware version
0.00~99.99
0.01
H0.23
Keypad firmware version
0.00~99.99
0.01
H0.24
Product series number
higher bits
0~65535
H0.25
Product series number
lower bits
0~65535
H0.26
OTP version
0.00~99.99
