CDE360 Vector Control AC Drive Chapter 2 Product Information
Table 2- 3 CDE360-4T class model and technical parameters
AC drive model
CDE360-
Power
capacity
（KVA）
Input current
（A）
Output
current
（A）
Brake unit
DC reactor
Keypad
4T0R7G/1R5L
2.0/3.0
3.4/5.0
2.6/3.8
Built-in
(Standard)
Not
installed
LED
(Standard)
4T1R5G/2R2L
3.0/4.0
5.0/5.8
3.8/5.5
4T2R2G/3R7L
4.0/5.9
5.8/10.5
5.5/9
4T3R7G/5R5L
5.9/8.9
10.5/14.6
9/13
4T5R5G/7R5L
8.9/11
14.6/18
13/17
4T7R5G/011L
11/16.4
18/25
17/24
4T011G/015L
16.4/21
25/31.2
24/30
4T015G/018L
21/24
31.2/39.2
30/38
4T018G/022L
24/30
39.2/46.5
38/45
4T022G/030L
30/40
46.5/62
45/60
4T030G/037L
40/57
62/78
60/76
4T037G/045L
57/69
78/93
76/91
External
(Optional)
External
(Optional)
4T045G/055L
69/85
93/114.5
91/112
4T055G/075L
85/114
114.5/153.5
112/150
4T075G/090L
114/134
153.5/180
150/176
4T090G/110L
134/160
180/214
176/210
4T110G/132L
160/192
214/256
210/253
Remarks:
1) The models of 15G/018L and below do not have input phase loss protection.
2) The models of 110G/132L and below are single and wall-mounted type.
3） 4T class (three-phase 380V AC input)
Table 2- 4 CDE360-5T class model and technical parameters
AC drive model
CDE360-
Power
capacity
（KVA）
Input current
（A）
Output
current
（A）
Brake unit
DC
reactor
Keypad
5T0R7G/1R5L
2.0/3.0
3.4/5.0
2.6/3.8
Built-in
(Standard)
Not
installed
LED
(Standard)
5T1R5G/2R2L
3.0/4.0
5.0/5.8
3.8/5.5
5T2R2G/3R7L
4.0/5.9
5.8/10.5
5.5/9
5T3R7G/5R5L
5.9/8.9
10.5/14.6
9/13
5T5R5G/7R5L
8.9/11
14.6/18
13/17
5T7R5G/011L
11/16.4
18/25
17/24
