CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-68-
Function
Code
Name
Range
Default
Step
Description
d6.11
Motor 2 Upper torque
limit Source of reverse
motoring
0~7
0
1
0: d6.12
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d6.12
Motor 2 Preset upper
torque limit of reverse
motoring
0.0~300.0
150.0
0.1%
d6.13
Motor 2 Upper torque
limit Source of forward
generating
0~7
0
1
0: d6.14
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d6.14
Motor 2 Preset upper
torque limit of forward
generating
0.0~300.0
150.0
0.1%
d6.15
Motor 2 Upper torque
limit Source of reverse
generating
0~7
0
1
0: d6.16
1: AI1
2: AI2
3: AI3
4: X6/FI
5: Communication
6: MIN（AI1,AI2）
7: MAX（AI1,AI2）
d6.16
Motor 2 Preset upper
torque limit of reverse
generating
0.0~300.0
150.0
0.1%
d6.17
Motor 2 proportional gain
of flux current loop
0~30000
2000
1
d6.18
Motor 2 integration time
of flux current loop
0~30000
800
1
d6.19
Motor 2 proportional gain
of torque current loop
0~30000
2000
1
d6.20
Motor 2 integration time
of torque current loop
0~30000
400
1
