CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-79-
Function
Code
Name
Range
Default
Step
Description
F0.20
Fault protection action selection 2
0000~2222
0000
1
Unit's digit: motor underload
0: Coasting stop
1: Stop by stop mode
2: Jump to 8% motor rated frequency, resume to
setting frequency when underload is inactive.
Ten's digit: Motor overheat（same as F0.19 unit's digit）
Hundred's digit: external fault（same as F0.19 unit's digit）
Thousand's digit: RS485 communication fault（same as F0.19 unit's digit）
F0.21
Fault protection action selection 3
0000~2222
0000
1
Unit's digit: Optional card communication fault（same as F0.19 unit's digit）
Ten's digit: PID feedback over limit（same as F0.19 unit's digit）
Hundred's digit: Accumulated power on time reached fault（same as F0.19 unit's digit）
Thousand's digit: Accumulated running time reached fault（same as F0.19 unit's digit）
F0.22
Fault protection action selection 4
0000~2222
0000
1
Unit's digit: Too large speed deviation（same as unit's digit）
Ten's digit: motor over speed（same as unit's digit）
Hundred's digit: flux postion detection failt（same as unit's digit）
Thousand's digit: UVW signals feedback fault（same as unit's digit）
F0.23
Fault protection action selection 5
0000~2222
0000
1
Unit's digit: Encoder fault
0: Coasting stop
1: Switchover to V/f, and stop by stop mode
2: Swtichover to V/f, and continue running
Ten's digit: User-defined fault 1（same as unit's digit）
Hundred's digit: User-defined fault 2（same as unit's digit）
Thousand's digit: Multi pump interlock fault（same as unit's digit）
F0.24
Frequency selection for continuing
to run upon fault
0~4
0
1
0: Current running frequency
1: Setting frequency
2: Upper limit frequency
3: Lower limit frequency
4: Backup frequency upon abnormality
F0.25
Backup frequency upon abnormality
0.0~100.0
100.0
0.1%
F0.26
Fire mode enable
0~1
0
1
0: Disabled
1: Enabled
F0.27
Fire mode frequency
0.00~b0.00
50.00
0.01Hz
F0.28
Fire mode PID setting increase
0.0~200.0
10.0
0.1%
