CDE360 Vector Control AC Drive Chapter 6 Parameters Description
PLC retentive upon stop indicates that the AC drive records the PLC running moment and running
frequency upon stop and will continue running from the recorded moment after it starts up again. If
the ten's digit is set to 0, the AC drive restarts the PLC process after it starts up again.
E3.02
Range: 0~1
Default: 0
Time unit of simple PLC
running
Setting the time unit for simple PLC running.
0: s (second) 1: h (hour)
E3.03
Range: 0.0~6553.5
Default: 0.0
Running time of simple
PLC reference 0
Unit: Sec(h)
Setting the time for simple PLC reference 0 running.
E3.04
Range: 0~3
Default: 0
Acceleration/
deceleration time of
simple PLC reference 0
0: Acceleration/deceleration time 1(As b0.04,b0.05)
1: Acceleration/deceleration time 2(As E4.00,E4.01)
2: Acceleration/deceleration time 3(As E4.02,E4.03)
3: Acceleration/deceleration time 4(As E4.04,E4.05)
The parameter descriptions of simple PLC Reference 1 to 15 are the same with Reference 0(E3.03
and E3.04).
E3.05
Running time of simple PLC reference 1
E3.21
Running time of simple PLC reference 9
E3.06
Acceleration/deceleration time of
simple PLC reference 1
E3.22
Acceleration/deceleration time of simple
PLC reference 9
E3.07
Running time of simple PLC reference 2
E3.23
Running time of simple PLC reference 10
E3.08
Acceleration/deceleration time of
simple PLC reference 2
E3.24
Acceleration/deceleration time of simple
PLC reference 10
E3.09
Running time of simple PLC reference 3
E3.25
Running time of simple PLC reference 11
E3.10
Acceleration/deceleration time of
simple PLC reference 3
E3.26
Acceleration/deceleration time of simple
PLC reference 11
E3.11
Running time of simple PLC reference 4
E3.27
Running time of simple PLC reference 12
E3.12
Acceleration/deceleration time of
simple PLC reference 4
E3.28
Acceleration/deceleration time of simple
PLC reference 12
E3.13
Running time of simple PLC reference 5
E3.29
Running time of simple PLC reference 13
E3.14
Acceleration/deceleration time of
simple PLC reference 5
E3.30
Acceleration/deceleration time of simple
PLC reference 13
E3.15
Running time of simple PLC reference 6
E3.31
Running time of simple PLC reference 14
E3.16
Acceleration/deceleration time of
simple PLC reference 6
E3.32
Acceleration/deceleration time of simple
PLC reference 14
E3.17
Running time of simple PLC reference 7
E3.33
Running time of simple PLC reference 15
E3.18
Acceleration/deceleration time of
simple PLC reference 7
E3.34
Acceleration/deceleration time of simple
PLC reference 15
E3.19
Running time of simple PLC reference 8
E3.20
Acceleration/deceleration time of
simple PLC reference 8
