CDE360 Vector Control AC Drive Chapter 6 Parameters Description
H1.05
AI2 display voltage 1
H1.09
AI3 display voltage 1
H1.06
AI2 actual voltage 2
H1.10
AI3 actual voltage 2
H1.07
AI2 display voltage 2
H1.11
AI3 display voltage 2
These parameters of H1.12~H1.19 are used to calibrate analog outputs, they have been calibrated
upon delivery. Generally, you need not perform correction in the common applications.
The actual voltage indicates the actual output voltage value measured by instruments such as the
multi-meter.
The display voltage is the drive calculated value, please see these parameters of A0.14~A0.15.
During calibration, input two voltage values to each AO terminal, and save the measured values and
displayed values to the function codes H1.12~H1.19, then the AC drive will calibrate AI zero offset
and gain automatically.
 H1.12~H1.15 are used to calibrate AO1.
 H1.16~H1.19 are used to calibrate AO2.
 When drive restore factory default value, H1.12~H1.19 will be resumed to factory
calibrated value.
H1.12
Range: 0.500~4.000
Default: Factory setting
AO1 display
voltage 1
Unit: V
It is used to input the AO1 display voltage(A0.14).
H1.13
Range: 0.500~4.000
Default: Factory setting
AO1 actual
voltage 1
Unit: V
It is used to input the AO1 measured voltage.
H1.14
Range: 6.000~9.999
Default: Factory setting
AO1 display
voltage 2
Unit: V
It is used to input the AO1 display voltage(A0.15).
H1.15
Range: 6.000~9.999
Default: Factory setting
AO1 actual
voltage 2
Unit: V
It is used to input the AO2 measured voltage.
The parameters used to calibrate AO2 as below:
Function Code
Name
H1.16
AO 2display voltage 1
H1.17
AO2 actual voltage 1
H1.18
AO2 display voltage 2
H1.19
AO2 actual voltage 2
