CDE360 Vector Control AC Drive Chapter 10 Optional Cards
250
10.5 Differential Encoder Card（PG1）
PG1 is an optional card for differential ABZ incremental encoder.It needs to be used together
with the vector control AC drives which is produced by our company..
 Functional overview
 Input ports for A,B,Z differential signal
 Optional supply(5V,12V and 15V) for encoder
 Pin description
Table 10-5 Optional card PG1
Terminal Symbol
Description
A+
Encoder output signal A Positive
A-
Encoder output signal A Negative
B+
Encoder output signal B Positive
B-
Encoder output signal B Negative
Z+
Encoder output signal Z Positive
Z-
Encoder output signal Z Negative
Vdd
Encoder supply
COM
Supply ground
 Installation of the optional card
Please see the figure 10-1.
