CDE360 Vector Control AC Drive Chapter 5 Parameter List Table
-55-
Function
Code
Name
Range
Default
Step
Description
25: Normally closed (NC) input of
external fault
26: Frequency modification
forbidden
27: Force main frequency
source A to b2.01+UP/DOWN
28: Force auxiliary frequency
source B to b2.01+UP/DOWN
29: Frequency source switchover
30: Motor 1/2 switchover
31: Pulse input
(enabled only for X6/FI)
32: Command source switchover
terminal 1
33: Command source switchover
terminal 2
34: Speed control/torque control
Switchover
35: Torque control prohibited
36: PLC status reset
37: Reverse PID action direction
38: PID pause
39: PID integral pause
40: PID parameter switchover
41: force PID wakeup
42: Counter input
43: Counter reset
44: length Count input
45: Length reset
46: Swing pause
47: Current running time reset
48: Motor 1# interlock input
49: Motor 2# interlock input
50: Motor 3# interlock input
51: Motor 4# interlock input
52: User-Defined fault 1 input
53: User-Defined fault 2 input
54: static auto tune
55: rotational auto tune
56: Force main frequency
source A to PID
57: Force main frequency
source A to PLC
58: Fire mode input
59: Broken line detection
C0.02
①
X2 function
0~58
23
1
Same As C0.01
C0.03
①
X3 function
0~58
0
1
C0.04
①
X4 function
0~58
0
1
C0.05
①
X5 function
0~58
0
1
C0.06
①
X6 function
0~58
0
1
C0.07
①
X7 function
0~58
0
1
C0.08
①
X8 function
0~58
0
1
C0.09
①
X9 function
0~58
0
1
C0.10
①
X10 function
0~58
0
1
C0.11
X1~X4 active mode
0000~1111
0000
1
0: Closed is active 1: Open is active
Unit's digit: X1
Ten's digit: X2
Hundred's digit: X3
Thousand's digit: X4
C0.12
X5~X8 active mode
0000~1111
0000
1
0: Closed is active 1: Open is active
Unit's digit: X5
Ten's digit: X6
Hundred's digit: X7
Thousand's digit: X8
C0.13
X9~X10 active mode
00~11
00
1
0: Closed is active 1: Open is active
Unit's digit: X9 Ten's digit: X10
C0.14
X1 delay time
0.0~3000.0
0.0
0.1Sec
C0.15
X2 delay time
0.0~3000.0
0.0
0.1Sec
C0.16
X3 delay time
0.0~3000.0
0.0
0.1Sec
