3-CONTROLSANDINSTRUMENTS

Rearandright-sidecameraviewoperatingmode.

(C)DEF/AdBlue®badquality,orSCRproblem.

SCRdetectioniconslowashing.

displayed.

Threeshortbeeps.

(D)After30minwithnoactiontaken.

SCRdetectioniconfastashing.

displayed.

Continuousbeep.

Atthestep(D),theoperationofthemachineshallbe

stopped.Reachasafeconditionforthemachine,and

immediatelycalltheCASECONSTRUCTIONdealerfor

inspectionandrepairoftheSCRsystem,andforreplace-

mentoftheuidintotheDEF/AdBlue®tankwiththe

properone.

SMIL16CEX1376AA23

3-96
