3-CONTROLSANDINSTRUMENTS

InducementsequenceforrepairingEGRsystem

Rearcameraviewoperatingmode.

SMIL19CEX2012AA24

(A)Normaloperation.

(B)EGRproblem.

SCRwarningsignsdisplayed.

displayed.

Onelongbeep.

(C)After36hwithnoactiontaken.

SCRdetectioniconslowashing.

displayed.

Threeshortbeeps.

(D)After100hwithnoactiontaken.

SCRdetectioniconfastashing.

displayed.

Continuousbeep.

Atthestep(D),theoperationofthemachineshallbe

stopped.Reachasafeconditionforthemachine,and

immediatelycalltheCASECONSTRUCTIONdealerfor

inspectionandrepairoftheEGRsystem.

SMIL17CEX0125BA25

3-97
