3-CONTROLSANDINSTRUMENTS

InducementsequenceforrepairingEGRsystem

Rearandright-sidecameraviewoperatingmode.

SMIL19CEX2011AA26

(A)Normaloperation.

(B)EGRproblem.

SCRwarningsignsdisplayed.

displayed.

Onelongbeep.

(C)After36hwithnoactiontaken.

SCRdetectioniconslowashing.

displayed.

Threeshortbeeps.

(D)After100hwithnoactiontaken.

SCRdetectioniconfastashing.

displayed.

Continuousbeep.

Atthestep(D),theoperationofthemachineshallbe

stopped.Reachasafeconditionforthemachine,and

immediatelycalltheCASECONSTRUCTIONdealerfor

inspectionandrepairoftheEGRsystem.
