3-CONTROLSANDINSTRUMENTS

IfanEGRsystemabnormalityisdetectedwithin40haftercompletionofEGRsystemrepair,andthedetectionlasts

for10s,themachinecontrolsystemimmediatelyresumestheinducementsequencetothestep(C).

Rearcameraviewoperatingmode.

(C)EGRproblem.

SCRdetectioniconslowashing.

displayed.

Threeshortbeeps.

(D)After5hwithnoactiontaken.

SCRdetectioniconfastashing.

displayed.

Continuousbeep.

Atthestep(D),theoperationofthemachineshallbe

stopped.Reachasafeconditionforthemachine,and

immediatelycalltheCASECONSTRUCTIONdealerfor

inspectionandrepairoftheEGRsystem.

SMIL17CEX0126AA28

3-99
